Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard

Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard
Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard
Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard

Large Image :  Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard

Product Details:
Place of Origin: China
Brand Name: lixian
Certification: CE
Model Number: HZ-1730
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: wood
Delivery Time: 7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: negotiate
Contact Now

Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard

Description
MOdel: HZ-1730 Product Name: Falling Ball Rebound Resilience Tester Equipment
Standard: ISO8307 Steel Ball Falling From: 500±0.5%mm(American Standard)
Ball Diameter: 16±0.05 Mm Precision Ball Drop Resilience: <1.5%
Sample Size: 100 Mm(L) *100 Mm(W)* 50mm(H) Display: LCD
The Average Rebound Debugging: Automatic Calculation Test Data: Can Be Printed
Highlight:

Foam Rebound Resilience Testing Machine

,

Drop Ball Rebound Resilience Tester

,

ISO 8307 Ball Rebound Resilience Tester

Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard



Product Description

ISO8307 Falling ball rebound Resilience Tester equipment is applicable to the determination of flexible polyurethane foam rebound performance off the ball. The instrument by the quality of a given ball diameter and height of free fall in the provisions of foam samples, the calculation of the maximum ball height and ball rebound height ratio of the Percentage drop, that resilience to rebound said foam rebound performance.



This machine uses microprocessor control,LCD Chinese display, and can print the test data. This machine has the use of
safe,reliable, measurement accuracy.Double-quick slicing machine for cutting Rubber Research Institute of plasticity of the specimen, from 16 ring knives and two 100 single-edged knife cutting round 10mm diameter, 16mm thick standard sample, without replacement of tools, easy operation, appearance and internal structure have been re-designed to make the performance more reliable, more beautiful shape for the domestic new improved plasticity sampler.

Main Feature:
1. 500mm samples can make the U.S. standard. (National standard of similar products can only do 460 samples)
2. LCD screen, the Chinese showed the same time increase the service life, easy to understand, technicians can quickly grasp the method of operation. (Similar products for the digital display, digital display only) 3, With printing, with printers. (Similar products without printing)

The Main Configuration And Accessories:
Host set (which includes the release of bodies to capture body height adjusting mechanism)
A set of electro-optical distance sensor Control box set (LCD display)
A micro-printer (desktop)

Specification
Model Number
HZ-1730
Product name
Falling ball rebound Resilience Tester equipment
standard
ISO8307
Steel ball falling from
500±0.5%mm(American standard)
Ball diameter
16±0.05 mm
Precision ball drop resilience
<1.5%
Sample size
100 mm(L) *100 mm(W)* 50mm(H)
display
LCD
test data
can be printed
the average rebound debugging
Automatic calculation





Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard 0



Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard 1



Drop Ball Foam Rebound Resilience Testing Machine Equipment Meeting ISO 8307 Standard 2
