Tape 180 And 90 Degree Peel Strength Test Machine For Steel Plate, Tape, Adhesive, Label ASTM D3330 Computer Servo

Tape 180 And 90 Degree Peel Strength Test Machine For Steel Plate, Tape, Adhesive, Label ASTM D3330 Computer Servo
Tape 180 And 90 Degree Peel Strength Test Machine For Steel Plate, Tape, Adhesive, Label ASTM D3330 Computer Servo
Tape 180 And 90 Degree Peel Strength Test Machine For Steel Plate, Tape, Adhesive, Label ASTM D3330 Computer Servo Tape 180 And 90 Degree Peel Strength Test Machine For Steel Plate, Tape, Adhesive, Label ASTM D3330 Computer Servo Tape 180 And 90 Degree Peel Strength Test Machine For Steel Plate, Tape, Adhesive, Label ASTM D3330 Computer Servo Tape 180 And 90 Degree Peel Strength Test Machine For Steel Plate, Tape, Adhesive, Label ASTM D3330 Computer Servo

Large Image :  Tape 180 And 90 Degree Peel Strength Test Machine For Steel Plate, Tape, Adhesive, Label ASTM D3330 Computer Servo

Product Details:
Place of Origin: China
Brand Name: lixian
Certification: CE
Model Number: HZ-1007E
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: negotiate
Packaging Details: wood
Delivery Time: 7 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Contact Now

Tape 180 And 90 Degree Peel Strength Test Machine For Steel Plate, Tape, Adhesive, Label ASTM D3330 Computer Servo

Description
Maximum Load: 1KN Effective Tensile Space: 300mm
Measuring Accuracy:: The Value ±1% / The Value ±0.5% Overload Protection: Overload 10%,automatic Protection
Power Supply: 220V 50Hz Weight: About 160 Kg
Packing: Wooden Case Packing Aplicable Industry: Steel Plate, Tape, Adhesive, Label
Highlight:

90 Degree Peel Strength Test Machine

,

ASTM D3330 Peel Strength Test Machine

,

Steel Plate Peel Strength Test Machine

500N, 1KN (Optional ) Electronic Polarizer 180 Degree Peel Test Machine Hz-1007e



Equipment summary:
It is a Steel plate tape peeling testing machine that combined with the electronic technology and mechanical transmission, it has accurate load speed, range of force measurement, Has high accuracy and sensitivity for the load, displacement measurement and control, Steel plate 180 Degree Peel Tester using single-space structure, operational space at the bottom, it is mainly applied to test Steel plate material which the load is less than 1KN, it has the parameters, such as stress, strain, control mode of displacement,calculated max force, tensile strength, bending strength, compressive strength, elastic modulus, rate of elongation, yield strength and others.

Main Function
This Series machine can be applied to test lots of materials in tensile,compression, tear, Adhesive Tape peel ( 90 degrees and 180 degrees) and other small mechanical test(within 1KN), such as rubber, tires, belt, shoes, plastic, film, acrylic, FRP, ABS, EVA, PU, aluminum-plastic pipe, composite materials, waterproof materials, fibers, textiles, wire and cable, paper, gold foil, ribbons, thread, spring, wood, medicine packaging materials, tapes etc.


Corresponding standard:
ASTM D3330, ASTM D882, JIS K 6854, ASTM E4, ASTM D828, ASTM D1938, ASTM F88, ASTM F904, ISO 37, JIS P8113.

Technical parameters:
Model Number
HZ-1007E
Accurate grade
1grade/0.5 grade
Certification
CE/ROHS/ISO
Material testing machine Maximum load
1KN
Effective measuring range
0.2%~100%/0.4%~100%
application 90 degree peel strength test machine
Measuring accuracy
the value ±1%/ the value ±0.5%

①. Single test, 10-point statistics manually and automatically calculate its average and break values;
②. Multi-unit automatically exchange such as kgf, Lbf, N, ton
③. Function of free to take point;
④. With multi-calibration function;
⑤. Auto printing function;
⑥. Using 24-bit AD acquisition, resolution 1 / 200000;


Tape 180 And 90 Degree Peel Strength Test Machine For Steel Plate, Tape, Adhesive, Label ASTM D3330 Computer Servo 0

Tape 180 And 90 Degree Peel Strength Test Machine For Steel Plate, Tape, Adhesive, Label ASTM D3330 Computer Servo 1

Tape 180 And 90 Degree Peel Strength Test Machine For Steel Plate, Tape, Adhesive, Label ASTM D3330 Computer Servo 2
